TERRA 6K, Smallest, Cine Camera with high performance, easy to be used like DSLR. TERRA 6K works up to 100fps @4K Wide, 200fps@ 2K Wide and record ProRes422HQ(.mov) onto standard 2.5″ SSD. The TERRA 6K imaging sensor is the same 6K wide-color-gamut CMOS sensor (rolling shutter) with KineMAX 6K. It features very high resolution, wide latitude and high fps. 6K Resolution  TERRA 6K is capable of recording 6K ProRes. 6K details and framing space is beyond imagination, > 18Million pixels in one frame: 9 times of Full HD/1080p, 2.25 times of UHD/3840×2160! 16/14 stops TERRA 6K employs state-of-art CMOS sensor: 14 stops at 6K resolution; amazing 16 stops at golden 3K/2K (S35 framing) . It brings you not only maximum details, but also maximum latitude in every frame. Rolling Shutter TERRA 6K shares the same state-of-art 6K CMOS sensor (rolling shutter) with KineMAX 6K. It is rolling shutter type, then suffers some rolling effect especially at 6K resolution. However, TERRA 6K features HiSpeed mode to record 4K/3K/2K which reduces rolling effect greatly.

tr_resolution


4K 100FPS TERRA 6K has very good slow-mo ability.  It supports 4K Wide Slow-Mo up to 100fps at HiSpeed S35 and 2K Wide to 225fps at HiSpeed S16. As of quick-mo, the minimum fps is down to 6fps. Any custom sensor fps can be set between lowest and highest fps with step of 0.001fps.
ProRes for All Res and All Fps   ProRes recording directly. For ProRes codec, it does not only support regular 2K/4K ProRes, but also has ability to record ProRes 422HQ for all resolution and all fps which the TERRA 6K supports, like 6K ProRes, 4K wide 100fps ProRes, 2K@200fps for HiSpeed mode. Apple ProRes as an industry standard is widely supported by DI/NLE softwares. TERRA 6K with ProRes speeds up both shooting and post-workflow at the same time.
2.5″ SSD recording media TERRA 6K employs standard 2.5″ 7mm SSD SATA3.0 as recording media to provide compatibility of 3rd-party SSD, though TERRA 6K is so small. There are lots of off-the-shelf 7mm SSD available. However performance of 3rd party SSD is not guaranteed, only official 7mm KineMAG 500G/1T SSD is recommended for serious shootings.
Custom in-camera LUT  You can upload the LUT/color style which you like, or DP like, or designed by post house to TERRA 6K, so that the workflow from shooting to post will be optimised and reduce the time for you, also help on-site lighting and art work. For recording KRW or ProRes with custom LUT, it does not burn into footage: footage is always logged (by KineLOG3), on-site LUT for monitoring is saved to the same folder. The size of 3D LUT is from 8x8x8 up to 33x33x33.
Multi-Framing Oversampling + Crop mode + KineEnhancer = infinity combination of resolution, fps and framing. With the help of in-camera oversampling, TERRA 6K records to 6K ProRes, but also 4K/3K/2K ProRes with sharper and more clean images at S35. The framing can be from S35 up to full frame if using KineEnhancer, while cropping mode can boost the higher fps. TERRA 6K supports above three modes to get multi-framing and multi res, at different fps.
4.3
4K 4:3 Anamorphic TERRA 6K as 4320×3240@25fps. and Aspect ratio of 4:3 matches anamorphic lens with factor of 2, so that it will gain CinemaScope frame as 8:3(2.66:1). With the desqueezed process in post-workflow, it can reach up to 7400×2800/7200×2700/8640×3240 (8K) CinemaScope!
KineMOUNT as Omni Mount KineMOUNT is the native lens mount of TERRA 6K. It provides enough possibility due to its short FFD(15mm). New KineMOUNT is re-designed to be light with electronic contact (active) in order to support new PL mounting adapter with /i tech and new cordless EF mounting adapter, EF mounting adapter with KineEnhancernew SONY FE/E mounting adapter, EF/PL mounting adapters with electronic ND(e-ND), etc.
Whole-new Accessories A group of whole-new accessories are designed specifically for TERRA, so that TERRA can be configured for one-man job or a professional filmmaking crew. KineBACK provides more than SDI monitoring, XLR 48V audio, V-mount plate, regulated DC output, timecode sync and 3D sync in one little module. KineMON as fullHD 5″ monitor is powered and is fed video from TERRA body by only one cord. SideGrip, as new handgrip w/ powering and control from GripBAT 45Wh(BP-U30 compatible) battery, more than one hour for usage. KineBAT 120Wh as Super compact V-mount battery provides over four hours to TERRA. KineKIT-TERRA from Movcam takes into account of TERRA in different scenarios, such as hand-held, tripod, on shoulder, gimbal, high and low shooting angles, etc., which makes it best choice for TERRA.
Create, no boundaries. As a small and powerful cinema camera, TERRA 6K is designed from bottom to top to facilitate filmmaking from shooting to post workflow. The value and flexibility from the TERRA 6K lets you put more of your production budget and energy into what goes in front of the camera. It’s a serious film-making tool with real Digital Cinema Camera features at such a price within reach.

Note: All trademarks mentioned belong to their respective trade mark holders and companies, and are not necessarily affiliated with our company and may not endorse our products or the use of their products with our products.

RESOLUTION, FRAME RATE AND CODECS
Image Format Format Resolution Max FPS Codec
S35 6K HD 5760x3240 30 ProRes or KRW
6K HD Wide 5760x2400 40 ProRes or KRW
4K HD (Oversample) 3840x2160 30 ProRes
4K HD Wide  (Oversample) 3840x1600 40 ProRes
4K HD (HiSpeed) 3840x2160 74 ProRes or KRW
4K HD Wide (HiSpeed) 3840x1600 100 ProRes or KRW
Golden 3K 2880x1620 30 ProRes or KRW
Golden 3K Wide 2880x1200 40 ProRes or KRW
Golden 2K HD (Oversample) 1920x1080 30 ProRes
Golden 2K HD Wide (Oversample) 1920x800 40 ProRes
M4/3 4.3K 4:3 Anamorphic 4320x3240 30 ProRes or KRW
4K 4:3 Anamorphic 4096x3072 30 ProRes or KRW
4K 4096x2160 44 ProRes or KRW
4K Wide 4096x1716 56 ProRes or KRW
4K HD 3840x2160 44 ProRes or KRW
4K HD Wide 3840x1600 60 ProRes or KRW
3K HD (HiSpeed) 2880x1620 115 ProRes or KRW
3K HD Wide (HiSpeed) 2880x1200 150 ProRes or KRW
Golden 2.2K Ana 2176x1620 30 ProRes or KRW
Golden 2K Ana 2048x1536 30 ProRes or KRW
Golden 2K 2048x1080 44 ProRes or KRW
Golden 2K Wide 2048x860 54 ProRes or KRW
Golden 2K HD 1920x1080 44 ProRes or KRW
Golden 2K HD Wide 1920x800 60 ProRes or KRW
S16 3K 3072x1620 59 ProRes or KRW
3K Wide 3072x1280 75 ProRes or KRW
3K HD 2880x1620 59 ProRes or KRW
3K HD Wide 2880x1200 75 ProRes or KRW
2K (HiSpeed) 2048x1080 170 ProRes or KRW
2K Wide (HiSpeed) 2048x800 200 ProRes or KRW
2K HD (HiSpeed) 1920x1080 170 ProRes or KRW
2K HD Wide (HiSpeed) 1920x800 225 ProRes or KRW
16mm 2K 2048x1080 88 ProRes or KRW
2K Wide 2048x860 110 ProRes or KRW
2K HD 1920x1080 88 ProRes or KRW
2K HD Wide 1920x800 118 ProRes or KRW
Note: Frame Rate can be adjusted as 2~MAX fps, step accuracy of 0.001fps.
TECHNICAL SPECIFICATION
Camera Type S35 Film-Style Digital Cinema Camera
Imaging Sensor 6K S35 Format CMOS Crop factor over FF: 1.6
Shutter Rolling Shutter
Lens Mount Native KineMOUNT as omni mount to be PL/EF/SONY E/Nikon F by solid mounting adapters *PL, PL e-ND *EF, EF e-ND, EF Enhancer *SONY E *Nikon F, F Enhancer
Record Formats Codec Type Codec Format Bit Depth
Compressed Lossless KineRAW .krw 12bits
ProRes422HQ/422/422LT/Proxy .mov 10bits
Record Res 6K 4K Golden 3K
5760x3240 3840x2160 2880x1620 4320x3240, 4:3
Max FPS 30@6K 100@4K Wide 150@3K Wide 225@2K HD Wide
Dynamic Range 16 stops/14 stops *Golden 3K/regular 6K
ISO/EI Base Max
1600/800 20480 *Golden 3K/regular 6K
Shutter Angle 0.7°~358°
Monitoring KineMON Port x1 HD Port x1 SDI x2* *Applicable on KineBACK
Record Media 2.5" SSD with 7mm Height
Audio Capture In-camera MIC; 3.5mm MIC-in; KineAudio* with 48V Phantom Power XLR *Applicable on KineBACK
Sync Function Tally, AutoSlate, Beeper, Trigger, SMPTE LTC*, 3D/Multi-cam Sync* *Applicable on KineBACK
LUT Preset: Neutral/Flat, Support Custom LUT
Power Power In Consumption
DC IN 11~19V/SideGrip/V-Mount* 21W *Applicable on KineBACK
Body Color Deep Grey
Weight 2.1 lb / 980 g *Only Body
Size 4.5x4.3x3.7" / 115x110x95 mm *W/o projections, WxHxL
Operating Temp 0°C to +40°C
Note:
  1. ALL SPECIFICATIONS SHOWN ARE PRELIMINARY AND SUBJECT TO CHANGE WITHOUT NOTICE;
  2. Any other trade marks belong to their respective owners.

Firm is the soul of camera. The KineOS5.0 on TERRA 6K keeps simple as previous version and also has many features for a professional cinema camera. It is responsive, clean and easy to access:
Advanced Waveform  TERRA 6K has waveform in-camera: you don’t need to buy monitor with waveform. Using waveform, cameraman can judge exposure quickly and accurately.
ZOOM and Focusing TERRA 6K provides Zoom to help focusing: full, 100%, 200%, 800%. Just press the Zoom button to toggle zoom ratio quickly. Zoom to 800% provides an interesting focusing signal: aliasing clear means focusing right.

Accurate Automatic WB  TERRA 6K provides accurate Automatic WB, so that you can deal with complicated lighting environment easily. Just use grey card or white card before lens, to set the WB accurately instantly. TERRA 6K would save the parameter into camera for later usage. Besides, TERRA 6K has two options for white-balance list: simple list and complete list. The complete list contains a long list for different lighting and different WB value (step is 50K) . For most cases, an appropriate WB setting you could find to match your condition.
Histogram with Tick Mark *(Not available yet) TERRA 6K integrate not only histogrm, but also special tick mark: 18% grey and 90% white respectively.

Accurate and custom sensor fps   You can set any custom sensor fps between lowest (6fps at current firmware) and highest fps (different for different resolution and different framing), the accuracy is 0.001fps, while recording fps is set by project fps in the camera. It provides much more possibilities over fixed fps like 24, 25, 30fps. So that you are free to create more amazing videos with different fps.
Presets for Parameters  In-Camera Presets are a set of parameters for recording: Resolution, FPS, Record format, Shutter speed, etc; and there are EIGHT in-camera presets, and it provides quick switch for these presets: BACK/VIEW button to pop up the Preset Shortcut list.

Anamorphic Lens  If you have anamorphic lens and want to give super wide effect, TERRA fulfills the dream. TERRA 6K supports 4K 4:3 anamorphic frame size, and de-squeeze images into normal images in live view and playback, just setting the display ratio according to your anamorphic ratio. For example, you will get 8K image effect if you use 2:1 anamorphic lens in 4K 4:3 mode for TERRA 6K; All you have to do is set the anamorphic ratio in configure menu.
Framing Ratio: 2.39:1   TERRA 6K supports 2.39:1 liveview and recording natively, besides 16:9 or 2:1 framing ratio. 2.39:1 is DCI scope standard, which is often used in short film and cinema projection.

Smart FAN Control  TERRA 6K has in-camera fan to cool the camera itself and make camera work well in stable condition. Fan generates noise. You can choose Record Stop in Fan setting to make FAN stop works temporarily: Fan works when live view; Stops when recording begins so that it is totally quiet when recording. It is very important in quiet environment, and sensitive to any audible noise. Strongly Recommend fan running when recording ProRes.
Upgrade Firmware by USB   TERRA 6K functions more than just a data table, by updating firmware. Updating firmware is easy and quick: download firmware, copy it into USB flash thumb, insert to TERRA 6K USB port, press upgrade in the menu. The update job is done after 15 mins.

Iris-Control on EF Lens   TERRA 6K supports majority of lens with iris-control as soon as you buy camera with native EF mount or active EF mounting adapter for KineMOUNT mount. TERRA displays Iris number and tune it directly. Also you can just disable electronic active EF mounting adapter so that protects it from all-metal lens backend. Check the compatible lens white list. EF Lens Compatible White-List
Real 3D Shots TERRA 6K can take real 3D shots. Just one SYNC cable to connect two TERRA SYNC port, set up Master and Slave instantly. 3D SYNC means: Scan sync, frame sync and time code sync, less than 5us of mismatch! For a multi-camera sync system (more than two), all TERRA cameras need to be equipped with KineBACK. Besides, you should purchase a KineSYNC device and a few SYNC cords: one KineSYNC device can sync up to eight TERRAs (one master camera and seven slave cameras).

Shot by TERRA 6K:
TERRA 6K shares the same state-of-art 6K CMOS sensor with KineMAX 6K, so it makes sense to evaluate image quality of TERRA 6K by shots of KineMAX 6K.
